A TYPE - 4-WHEEL STEERING WITH A STEERING KNUCKLE
-maximum large angle of the steering control system bend - 45°,
-load range - 1÷5 tones,
-loading surface 2.0x1.0m ÷ 5.0x2.0m - from pretreated wood,
-loading surface and load can be changed according to the customer's request,
-solid rubber or pneumatic tires,
-truck can be pulled or pushed,
-precise driving path along identical radius of front and back wheels
(no wheels overlapping during turning),
-can be combined into larger units,
-replaceable drawbar, secured in a vertical position,
-additional elements: sideboards, top attachment with canvass cover.
D TYPE - STEERED WITH ONE TURNTABLE
-maneuverable, does not need to be maintained,
-load range - 1÷5 tones,
-loading surface 2.0x1.0m ÷ 5.0x2.0m from pretreated wood,
-loading surface and load can be changed according to the customer's request,
-solid rubber or pneumatic tires,
-permanent drawbar secured in a vertical position,
-additional elements: brakes, sideboards, top attachment with canvass cover.
DD TYPE - STEERED ON TWO AXLES WITH TWO TURNTABLES
-wheels turning by 35°, load range - 1÷5 tones,
-loading surface 2.0x1.0m ÷ 5.0x2.0m from pretreated wood,
-loading surface and load can be changed according to the customer's request,
-solid rubber or pneumatic tires,
-truck can be pulled or pushed,
-adjustable drawbar secured in a vertical position,
-small reverse radius,
-does not need to be maintained,
-can be combined maintaining the same driving path,
-additional elements: sideboards, top attachment with canvass cover.
A TYPE - 4-WHEEL STEERING WITH A STEERING KNUCKLE
-very small turning radius, load range - 8.0÷16 tones,
-loading surface 2.5x1.25m ÷ 5.0x2.0m,
-loading surface and load can be changed according to the customer's request,
-not easily overturn,
-twin solid rubber tires,
-truck built and finished according to,
-permanent drawbar with DIN 74054 forged catch secured in a vertical position.
D TYPE - STEERED WITH ONE TURNTABLE
-very maneuverable,
-load range - 8.0÷16 tones,
-loading surface 2.5x1.25m ÷ 5.0x2.0m,
-loading surface and load can be changed according to the customer's request,
-not easily overturn,
-twin solid rubber tires,
-permanent drawbar with DIN 74054 forged catch secured in a vertical position.
